ABB SattLine 200 Process Control System

Overview & Key Features

The ABB SattLine 200 is the central module of the SattLine Series 200 Distributed Control System (DCS), combining full DCS functionality with the flexibility of a powerful, modular hardware architecture. It is engineered for industrial automation environments that demand reliability, scalability, and unified control across operations of any size.

Using graphical, object-oriented configuration, a single programming language handles graphical operator interface, logic control, and supervisory functions. This unified design means the program structure follows the same logic and flow as the process itself, resulting in highly flexible programs, reduced development time, and a high degree of software integrity.

Key Features:

• Central DCS module combining control, logic, and HMI functionality in a single platform
• Object-oriented graphical configuration with one programming language across all functions
• Open architecture integrating seamlessly into the Microsoft Windows environment
• Standard Microsoft protocol support including ODBC and OLE/OPC for external data exchange
• Modular software structure with configuration, programs, libraries, and modules
• Library-based module design enabling reuse of process objects such as valves and event detection routines
• Scalable from small applications to large multi-plant installations without reconfiguring existing setups
• Upgrade path to actively supported SattLine CPU80 controllers and modern communication modules
• ABB conversion tools available for evolution to System 800xA, proven in several large plants

Atomic Answer: The ABB SattLine 200 is a central DCS module with object-oriented configuration that combines operator interface, logic control, and supervisory functions in a single programming environment. It supports ODBC, OLE, and OPC protocols, integrates with Microsoft Windows, and scales without replacing existing configurations.

---

Practical Applications / How It Works

The SattLine 200 is designed to maintain a consistent look, operation, and functionality regardless of the application or system size. This means operators and engineers can expand from a single subsystem to full plant-wide DCS deployment using the same architecture, without reconfiguration of existing components.

Real-World Use Cases:

• Continuous process industries such as pulp and paper, power generation, water treatment, and chemical manufacturing
• Plant-wide supervisory control where information must be exchanged with enterprise databases or external programs via ODBC or OPC
• Legacy Satt DCS installations that require secure, stepwise upgrades to CPU80 controllers or migration to ABB System 800xA
• Facilities needing high software integrity through reusable process modules stored in centralized libraries
• Environments requiring open integration with Microsoft Windows tools and standard IT protocols

How It Works: Control programs are built by designing and assembling modules (objects). Lower-level modules implement process objects such as valves or basic functions such as event detection, while higher-level modules combine these to represent entire process sections. Each module is stored in libraries containing both graphics and program code, enabling reuse, standardization, and faster commissioning across the plant.

Sourced and supplied by Spare Parts Map, a global supplier of industrial spare parts with over 20 years of experience primarily serving European industries. Our team responds quickly to inquiries and ensures products are delivered without complications, so you can secure the spare parts your operation depends on.

---

Frequently Asked Questions (FAQ)

Q: What type of system is the ABB SattLine 200? A: The ABB SattLine 200 is a process control system central module that forms part of the SattLine Series 200 Distributed Control System (DCS). It combines DCS functionality with flexible, modular hardware architecture for industrial automation.

Q: Does the SattLine 200 support integration with Microsoft Windows and external databases? A: Yes. The SattLine 200 features an open system architecture that integrates easily into the Microsoft Windows environment. It exchanges information with external programs and databases using standard Microsoft protocols including ODBC and OLE/OPC.

Q: Can existing SattLine installations be upgraded to newer ABB platforms? A: Yes. ABB provides stepwise upgrade paths from SattLine Series 200 controllers to the actively supported SattLine CPU80 controller with new communication modules. ABB also offers conversion tools to evolve SattLine to System 800xA, with proven use in several large plants.

Q: How can I request a quote for the ABB SattLine 200? A: Spare Parts Map supplies the ABB SattLine 200 and related spare parts worldwide. Use the Request Quote option on this page to receive current availability, pricing, lead time, condition details, and worldwide delivery options. Our team responds to inquiries quickly, backed by over 20 years of industrial spare parts experience.
